Ford Fuel Injection

Truck Computer Pin outs
Year:	87-95	94-95	85-86	87-95	94-95	88-95	89-95	89-95	89-95
Engine:	300	300	302/351	302/351	302/351	460	E4OD additions	E4OD additions	4R70W additions
Vehicle:	Truck Van Bronco	Truck Van Bronco	Truck Van Bronco	Truck Van Bronco	Truck Van Bronco	Truck Van	Truck Van Bronco	Truck Van Bronco	Truck Van Bronco
Type:	Speed Density	Mass Air	Speed Density	Speed Density	Mass Air	Speed Density	Speed Density	Mass Air	ALL
Injector:	14lb/Hr	14lb/Hr	19lb/Hr	19lb/Hr	19lb/Hr	24lb/Hr
1	K A PWR	K A PWR	K A PWR	K A PWR	K A PWR	K A PWR
2							BOO	BOO	BOO
3	VSS (+)	VSS (+)		VSS (+)	VSS (+)	VSS (+)	VSS (+)	VSS (+)	VSS (+)
4	IDM	IDM	IDM	IDM	IDM	IDM
5									TSS (+)
6	VSS (-)	VSS (-)		VSS (-)	VSS (-)	VSS (-)	VSS (-)	VSS (-)	VSS (-)
7	ECT	ECT	ECT	ECT	ECT	ECT
8	FPM 89-95	FPM		FPM 89-95	FPM	FPM
9	Data Bus (-) 90-95	MAF-RTN		Data Bus (-) 90-95	MAF-RTN	Data Bus (-) 90-95
10	A/C on	A/C on	A/C on	A/C on	A/C on	A/C on
11	TAD	TAD	TAD	TAD	CANP	TAD
12		INJ 6			INJ 6		4LOW input
13					INJ 7
14					INJ 8
15		INJ 5			INJ 5
16	IGN-GND	IGN-GND	IGN-GND	IGN-GND	IGN-GND	IGN-GND
17	STO	STO	STO	STO	STO	STO
18		Data Bus (+)			Data Bus (+)
19		Data Bus (-)			Data Bus (-)		SS2
20	GND	GND	GND	GND	GND	GND
21	IAB	IAB	IAB	IAB	IAB	IAB
22	FPR	FPR	FPR	FPR	FPR	FPR
23	KS	KS	KS	KS 302 only	KS 302 only
24	PSPS 87-90			PSPS 302 only
25	ACT	ACT	ACT	ACT	ACT	ACT
26	V-REF	V-REF	V-REF	V-REF	V-REF	V-REF
27	EVP	EVP	EGR solenoid	EVP	EVP	EVP
28	Data Bus (+) 90-95			Data Bus (+) 91-95		Data Bus (+) 91-95
29	HEGO		HEGO	HEGO		HEGO			TSS(-)
30	NDS	NDS	NDS	NDS	NDS	NDS	MLPS	MLPS	MLPS
31	CANP 90-95	TAB		CANP	TAB	CANP
32							OD light	OD light	OD light
33	EVR	EVR	EVR	EVR	EVR	EVR
34		TAD			TAD
35		INJ 4			INJ 4
36	SPOUT	SPOUT	SPOUT	SPOUT	SPOUT	SPOUT
37	V-PWR	V-PWR	V-PWR	V-PWR	V-PWR	V-PWR
38							EPC	EPC	EPC
39		INJ 3			INJ 3
40	GND	GND	GND	GND	GND	GND
41							OD switch	OD switch	OD switch
42							TOT	4LOW input	4LOW input
43	A/C demand
44		HEGO			HEGO
45	MAP		MAP	MAP		MAP
46	SIG-RTN	SIG-RTN	SIG-RTN	SIG-RTN	SIG-RTN	SIG-RTN
47	TPS	TPS	TPS	TPS	TPS	TPS
48	STI	STI	STI	STI	STI	STI
49	HEGO GND		HEGO GND	HEGO GND		HEGO GND		TOT	TOT
50		MAF			MAF
51	TAB		TAB	TAB		TAB		SS1	SS1
52			EGR solenoid				SS1	SS2	SS2
53							TCC	TCC	TCC
54		A/C WOT off
55							CSS	CSS
56	PIP	PIP	PIP	PIP	PIP	PIP
57	V-PWR	V-PWR	V-PWR	V-PWR	V-PWR	V-PWR
58	INJ's 135	INJ 1	INJ's 1458	INJ's 1458	INJ 1	INJ's 1458
59	INJ's 246	INJ 2	INJ's 2367	INJ's 2367	INJ 2	INJ's 2367
60	GND	GND	GND	GND	GND	GND
Need Help with the Abbreviations, go here: Definitions & Abbreviations
